DZ47Z-63 DC MCB supplementary protectors are designed to provide over-current protection within appliances or electrical equipment, where a branch circuit protection is already provided or not required. Devices are designed for direct current (DC) control circuit applications.
Summary
| DZ47Z-63 DC Series Circuit Breaker | DZ47Z-63 | |
| Frame Degree Rated Current (A) | 63 | |
| Pole | 1P, 2P,3P, 4P | |
| Rated Operating Voltage (V DC) | DC12V -DC1000V | |
| Rated Current In (A) | 1-63A | |
| Rated Insulation Voltage Ui (V DC) | 1200VDC | |
| Rated Impact Voltage Uimp (kV) | 4 | |
| Ultimate Breaking Capacity lcu (kA) | 4.5 | |
| Run Breaking Capacity lcs (%lcu) | 100% | |
| Curve Type | C | |
| Trip Type | Thermal-magnetic | |
| Mechanical | Actual average value | 9700 |
| Standard value | 9700 | |
| Electric | Actual average value | 300 |
| Standard value | 200 | |
